Dual-axle output with convenient M10 threaded mounting.
The POL 20 Series is a robust industrial potentiometer designed for easy panel integration using an M10 threaded mounting system. It features a dual-sided shaft output that enables synchronized mechanical coupling or multi-axis control.
The design supports multiple connection formats including PCB mounting, stranded wire leads, and plug-terminated wiring, making it highly adaptable across varied system requirements. With configurable rotation options and precise electrical response, it is suitable for custom feedback applications.
Electrical, mechanical and environmental ratings for the POL 20 Series.
| Parameter | Value / Rating |
|---|---|
| Resistance Values | 1 kΩ, 5 kΩ, 10 kΩ |
| Linearity | ±1% |
| Electrical Angle | 320° (adjustable) |
| Resolution | Essentially Infinite |
| Mechanical Rotation | 360° continuous or 320° stopper |
| Shaft Configuration | Dual-sided axle output |
| Mounting Style | M10 threaded bushing |
| Shaft | High-durability steel alloy |
| Connection Types | PCB pins/pads, stranded wire leads, plug-terminated wires |
